AOK Series Air Diaphragm Pump

Inlet/Outlet Diameter: 6mm, 10mm, 15mm, 20mm, 25mm, 50mm, 80mm
Max Flow Rate
Max Air Pressure
Max Solid Size
Max Suction Lift: Dry, Wet
Material of Construction: Cast Iron, Aluminum, PP, PVDF, SS304, SS316

Description

PRODUCT DESCRIPTION

AOK series air diaphragm pump has the characteristics of simple structure, easy use and stable operation, which is same as Graco Husky brand diaphragm pump which can be interchanged with same performance. DEFU pneumatic diaphragm pumps are widely used in the chemical industry and can transport various strong acids and alkalis, such as sulfuric acid, hydrochloric acid, nitric acid, caustic soda, calcium hydroxide, etc. It can also transport various corrosive liquids, liquids with particles, high-viscosity liquids, volatile liquids, flammable and explosive liquids.

Download

AOK Series Schematic Diagram

DEFU air diaphragm pump are driven by compressed air. Air enters the air valve which will allow pressurized pneumatic air into one of the two chambers. As the air enters and fills the chamber on the left the flexible diaphragm expands and compresses the fluid on that side of the diaphragm. This effectively forces the upper valve to open, releasing the fluid into the discharge pipe system. At the same time, the discharge chamber is pumping liquid out of the pump, the opposite diaphragm is pulled in toward the center housing by the drive shaft.

PERFORMANCE DATA

Model No.	Inlet/Outlet dia (inch)	Max flow rate(m3/h)	Max head(m)	Max Solid Size(mm)	Max suction lift(m)	Max. Air Supply Pressure(kg/cm2)
QBK-06/10	1/4 or 3/8	1.62	70	1.6	6.4	7
QBK-15/20	1/2 or 3/4	3.42	70	2.5	7.6	8.4
QBK-25	1	9.42	84	4	8	8.4
QBK-40	1 1/2	21.48	84	5	8	8.4
QBK-50	2	35.22	84	6	8	8.4
QBK-80	3	63.6	84	9.4	8	8.4

PRODUCT FEATURES

Self-PrimingPerformance

The air operated diaphragm pump has the function of self-priming without rotating parts, it can achieve dry priming and wet priming.

Easy Maintenance Structure

With sectional type structure, this self-priming pump can be used for conveying two different liquid by double diaphragm.

High Quality Pump Material

The pump body of our water pump can be made by PVDF, PP, SS304, SS316 cast iron, aluminum alloy, etc. The diaphragm can be made by: Teflon, Santoprene, Buna-N, Viton etc.

Compact, Lightweight & Easy to Maintain

Small size, and light weight, easy to mobile, flexible installation, easy maintenance.

Higher Weight with Same Dimensions

DEFU's pump is heavier with thicker pump casing than other supplier's pump with same dimensions. If the pump casing is litter thin, the pump casing will be rupture and damaged once the pump work with high pressure.

No Dynamic Seals, Dry Running Safe

No dynamic seals, even dry running without damage to the pump.

APPLICATION

Beverage and Food Industry
Coatings and Paint Industry
Adhesive and Glue Industry
Ceramic Industry
Mine Industry
Cooling and Circulation
Environmental Protection and Wastewater Treatment Industry
Marine Industry

FAQ

1What are the performance specifications of the DEFU AOK series 2inch air diaphragm pump?

The DEFU AOK50 air diaphragm pump is engineered for critical chemical management applications with high performance:
Maximum Flow Rate: 587lpm ;
Maximum Discharge Pressure: 8.4bar;
Suction Lift Capacity: 5m for dry, 8m for wet;
Max Solid Particle Handling: 6mm

2Who are the global leaders in air diaphragm pump?

There are global Top 10 air diaphragm pump brand for reference: ARO, Graco, Wilden, Sandpiper, Yamada, Versa-Matic, All flo, Fluimac, Verder, Lutz and so on.

3What are the performance in leading global brand pump like Graco 2inch air diaphragm pump?

The Graco 2inch pump demonstrates the following performance characteristics:
Maximum Flow Rate: 568lpm ;
Maximum Discharge Pressure: 8.4bar;
Suction Lift Capacity: 5.48 m wet or dry;
Max Solid Particle Handling: 6.3mm
